Forged Compact Design Steel Flanges 1/2 Inch - 48 Inch And 150# To 2500# Size 1/2'-24'
BOYUE GROUP deal with Austenitic Stainless Steel, Nickel Alloy Steel(Hastelloy , Monel, Inconel, Incoloy ) , Copper Nickel alloy products (pipe, fitting, flange) already more than 25 years, every year sell more than 50000 tons of steel pipe and tube, and also supply millions fittings and flange. Our client already cover more than 45 countries, Like Italy, UK, Gernmany, USA, Canada, Chile, Colombia, Saudi Arabia, Russia, Korea, Singapore, Austrial, Poland, France , ....And our group branch company and factory have been already approved by :ABS, DNV, GL, BV, PED 97/23/EC, AD2000-WO, GOST9941-81, CCS, TS, CNNC, ISO9001-2015, ISO 14001, ISO 18001,...
Based on NORSOK L005 code, suitable for critical sealing applications with high thermal expansion, cyclic loading such as Risers, single point mooring systems, manifolds, X-Trees, subsea pipelines, heat exchangers and a multitude of process piping systems.
- RCF Advantage
- Space saving
- Weight saving up to 70%~80% than ANSI flanges
- Double Independent Seals make it er
- Integrated sealing system (both inside and outside)
- Larger range in design temperature and pressure
- RCF Working Principle
- The RCF compact flange design principle is that the flange face includes two independent seals. The first seal is created by application of seal seating stress at the flange heel. The main seal is the IX seal ring. The seal ring force is provided by the elastic stored energy in the stressed seal ring. Any heel leakage will give internal pressure acting on the seal ring inside intensifying the sealing action.RCF Size and Pressure Rating
- 1/2”~48” in size and Class 150# to 2500# in pressure rating.
- Bigger size and higher pressure rating on request.
- RCF Materials
- ASTM A105, A350 LF2, LF6, A694 F52~F70
- AISI 4130, AISI 8630
- A182 F316/316L, F51, F53, F55, Inconel 625, Incoloy 825.
- Other material on request
- RCF Gasket
- RCF IX seal ring, axial forces are exerted on the taper of the metal seal ring and translated into a radial sealing force. Furthermore with increased pre-load, the bevel is closed and face to face contact is achieved at the outer wedge while most of the bolt pre-load is transferred as compressive forces between the flange faces at the heel.
- RCF Design and Verification Applications of pipe flanges:
- boyue Special Steel provides calculation service based on ASME section VIII Division 1, 2 and 3. Also we have ANSYS software engineers to do the analysis and design verificatio
-
Pipe flanges are widely used in pipe fittings of various industrial, commercial and residential applications. Pipe flanges can be customized to suit your application with various machining details. These pipe flanges have been used extensively in:
- Hydraulic control systems for turbine generators
- High pressure ground support missile systems
- Nuclear and conventional power plant applications etc.
| DIN 2502 | DIN 2503 | DIN 2527 |
| DIN 2565 / 2566 | DIN 2573 / 2576 | DIN 2627 / 2628 |
| DIN 2629 / 2630 | DIN 2631 | DIN 2632 |
| DIN 2633 | DIN 2634 | DIN 2635 / 2636 |
| DIN 2637 / 2638 | DIN 2641 | DIN 2642 |
| DIN 2655 / 2656 | DIN 86029 / 86030 | |
| Place of Origin | China | Brand Name | BOYUE |
| Standard | ANSI, ISO, ASME, DIN, ASTM | Type | SW/WN/SO/BL/TH Flanges |
| ModelNumber | Steel Flange | Thickness | #150,#300,#600,.#900,#1500,#2500 |
| Packing | Ply-Wood Cases | Payment | 30%TT+70% Balance |
Supply Ability:40000Pieces / per Month
Packaging & Delivery
Packaging Details:Generally plywooden case or following customer's requirement.
Port:Shanghai/Tianjin
Commerce Clause
| Minimum Order Quantity: | 1pcs |
| Price: | Depending on quantity |
| Payment Terms: | T/T or Western Union or LC |
| Supply Ability: | 40000pcs per month |
| Delivery Time: | 10-100 days depending on quantity |
| Packaging Details: | PLY-WOODEN CASE OR PALLET |
